Well hello there. This is my take on proton pack lights.

*Disclaimer:

My light kits were not originally intended to be fully featured light kits with all requisite bells and whistles.

They will continue to evolve as I learn new techniques and have time to implement them.

I won’t make any claims to screen accuracy. Some aspects are, some are not. I have certainly taken some creative liberties. Do some research and come to your own conclusion. Dimensions are available for your reference.*

Pack Light Kit v8 - $65

Includes:

Power cell with 15 gorgeous blue LEDs

4 red cyclotron LEDs (*some assembly required)

Master power switch

Optional video game style cyclotron fading (user-selectable)

Optional start-up sequence (user-selectable)

Interacts with v8 wand kit when connected via CAT5 cable

Lights speed up when firing, overloads after 12 seconds

Runs on 9-12V DC


Click for dimensioned drawing.

Overkill Cyclotron Lights - $25

  • 48 (less bright) red LEDs instead of the standard 4. yikes.

  • compatible with older kits (instructions coming soon)

  • 12V battery highly recommended

Wand Light Kit v8 - $85

Includes:

Bar graph - three styles to choose from

  • Continuous yellow (like v1-v7 bar graphs)

  • Segmented yellow

  • Segmented amber

Optional startup sequence (user-selectable)

5 auxiliary LEDs (*some assembly required)

Vent lights built into main circuit board

Multi-colored barrel lights

Video game style firing sequence

5 switches included (only 3 connect to the kit, the other two are for cosmetic purposes, *some assembly required)

Runs on 9-12V DC

There is now a Do It Yourself element which requires wire strippers and pliers at a minimum for BOTH kits. This is very easy to do, but I will do it for you for an extra $5.

Here are the instructions


Overkill Vent Lights - $10

  • 9 white LEDs positioned to shine through the vent slots on your gun box

  • plugs into v6 and v7 gun kits

  • Requires 9.6V or 12V battery

Aluminum Mounting Spacer Set


Standalone Barrel Lights - $15

  • for upgrading my v1 and v4 wand kits, or just to use by themselves

  • four LEDs (red, blue, white, yellow) that light up your barrel when firing

  • Round PCB is 0.8" in diameter and fits up against the 7/8" clear part of your barrel. It needs to be glued in place.

  • orange ear light is connected to barrel lights

  • includes standard pushbutton switch (black)

Combo

  • Includes both pack and wand kits, plus an 7ft cable to connect the two (for battery sharing and interactivity)

  • regular: $150 + shipping (pack kit and regular wand kit)

Sound Kit

Mine is not ready for prime time. I recommend Crix’ sound board. Must use DPDT switches to make it work with my lights right now.

Trap Kit

Maybe some day :stuck_out_tongue:

Wand Bar Graph Frames and holders


From left to right:

Aluminum frame - $6

Plastic v1-v7 bar graph frame and holder - $8

Plastic v8+ bar graph frame and holder - $15

The plastic holders hold the bar graph in place as well as provide a nice cosmetic frame. Both require painting.

These can now be purchased here: Shapeways & Thangs Marketplace for 3D Creators - Shapeways Blog

The aluminum frame is cut with a water jet and will sit on the flat face of the wand and go around the bar graph. It is NOT designed to have the bar graph LEDs actually go inside the frame, although it’s possible with some light filing. The bar graph should be flush with the face of your gun box. This will also help to cover up any shoddy hole cutting that may have occurred. You may wish to sand or file more, but for many people this will be ready to paint.

Click for dimensioned drawing.

This is not guaranteed to fit perfectly with other kits.

None of these are screen accurate, but a decent visual approximation. In any case, they help give the bar graph a clean look.

Note: the aluminum frame and the plastic frame/holders do not work together, it’s one or the other. The geometry of the aluminum frame is included in both of the plastic holders.

Customization

If you want something out of the ordinary, just let me know and if it’s feasible we’ll work something out.

I have done different light sequences and LED colors for some people.

Remember that the cyclotron and auxiliary gun lights can be easily replaced with different LEDs of your choice.

Limited supply of extra parts for sale:


  • Red/clear Cliplite LED cover - $2 for 2 red, 2 clear (or just 50 cents each)


  • Dixie-style v-hook - $5

  • red and blue acrylic for power cell and cyclotron - $5 per set

Wiring Diagrams

You can use any battery (from 7 to 18 volts) and any switch you want. There are screw terminals for each connection so no soldering is involved there. Each kit can be operated with a battery and a switch, OR you can wire them together and run them off the same battery and switch. PM me or post here with questions.

Click here for wiring diagrams

Shipping - NEW for v8

Within the United States:

$7 for one kit

$10 is the default for up to two kits.

More than a combo, I will let you know the cost on a case by case basis

You may request UPS for $15 instead.

International shipping: depends on fast you want it, PM me

Ordering

PM to get on my list.

I will send you a link to my order form.

I will only ship to the address provided in your PayPal payment. Make for dang sure it’s correct.

v6 video

NOTE: there is an “r2devo” on YouTube. This is not me. I go by MechaDoozer there.

Who am I? Who are we?

We’re Devin and Andrea, D&A!


Seller info:

Name: Devin ■■■■, Andrea Lucius

Location: Fort Collins, Colorado

I’m don’t have extensive education in electronics, this is just a hobby of mine. I am actually a full time mechanical engineer in the industrial automation industry. (i.e. industrial robotics!)

I am always learning new things and tweaking my designs, so every run is different and may include new features.

These get designed and assembled in our spare time, not as a means of primary income. We are proud to be part of the community.

Andrea is my woman of choice. Part of being my woman of choice includes soldering and cable assembly. She’s been doing a great job so far, so give 'er a hand! She’s also not an electrical guru, but a cartographer.

Check out my feedback or leave a comment for yourself right here: R2DEVO......... - Feedback - GBFans.com

Support

I’m also here for support, feel free to contact me via PM, here, Xbox Live, whatever.

Please give me a couple days to reply before you try again, I will try to get back to you in a timely manner.

Thanks for all your support and AJ for organizing this great site.

-Devin

edit: almost forgot! I’m putting together a tutorial for making your own lights right HERE
