can some one help me out , i’m looking for the belt gizmo dimensions, thanks
lol , what no one lol
according to my careful measurements it comes out to 18 inches tall, 5 inches wide, and about 4 inches deep.
Let me know if you need more help.
cheers , looking for a bit more if possible , some thing like a complete plan with sizes or just the sizes
cool man. I’m in the process of making an auto cad 3-d model of the belt gizmo using the measurements listed above. It’s going to be one of the most detailed renderings ever, even including the pixie tubes and Sony circuit board. My hope is that AJ will put it in the reference section. I’ve been working on it for about a year, but I should have it finished by this Thanksgiving. When it’s done I’ll post it for you.
sweet
How hard are you looking?
"Here are all the dimensions - use these to draw a paper template on graph paper, then use that template to cut out a base board on some stiff plastic:
Max width of the board is 95.5mm
Max height of the board is 147.6mm
Overall width of the edge connector is 72.6mm centered on board
Left edge connector is 44.9mm
Right edge connector is 24.7mm
Height of edge connector is 9.8mm
Side indents are 2.3mm deep
Side indents start about 49.3mm from the bottom (not including the edge connector) and are about 40.9mm tall
The exposed glass part of the gas-discharge displays is about 25.7mm tall and 10mm wide
The white chips are 23mm tall by 16.5mm wide (excluding legs) Metal window cover ones are about 1m thick while the non windowed ones are 2mm They are elevated off the board give or take 3mm
The black ICs are 20mm wide by 12mm in length and 3.9mm tall, they are elevated off the board give or take 1mm
The pillow shaped IC in the bottom right is 30.6mm by 12.5 and 3.5mm thick."
All posted on this site: http://www.tk2441.co.uk/gb-belt.htm which is linked to in many of the belt gizmo threads, or you can just use Jairus’s convenient PDF that prints out actual size.
Dude, what belt gizmo are you looking at? Those aren’t the dimensions I got. This makes me want to finish my auto cad gizmo rendering even quicker. I mean c’mon, anyone who uses M&Ms as a standard measurement, is far from trustworthy and completely not professional. Ever heard of a ruler?
True, that site doesn’t get it all right. It’s completely off on the screenused number of nixie tubes:
cheers guys thats just what i need
Actually I was going to start a new belt gizmo myself, but hadn’t started looking for info on it. Thanks, Jack.
